HERZ Braided Flexible Metal Hose
HERZ Braided Flexible Metal Hose
| Code | Description |
|---|---|
| HB20015 | Flexible Connector with Braiding DN 15 |
| HB20020 | Flexible Connector with Braiding DN 20 |
| HB20025 | Flexible Connector with Braiding DN 25 |
| HB20032 | Flexible Connector with Braiding DN 32 |
| HB20040 | Flexible Connector with Braiding DN 40 |
| HB20050 | Flexible Connector with Braiding DN 50 |
SKU: HB200
Details
| Component | Specification |
|---|---|
| Materials & Technical Data | |
| Hose Type | Braided flexible metal hose |
| Hose Material | Stainless Steel AISI 316L |
| Braiding Material | Stainless Steel AISI 304 |
| Union | Carbon Steel St.37.2 / Stainless Steel (FxF End connection) |
| Insulation | EPDM, Rubber based |
| Pressure Rating | PN25 |
| Temperature Range | -10°C to +90°C |
| Application |
|---|
|
The braided flexible metal hoses can be used safely and reliably on high-pressure installations. They are hermetic with long service life. Thanks to the flexible nodular construction, vibration effects are minimized and fluid transmission is ensured without any section narrowing. |
